• USB Capture AIO - one-channel HD capture box
  • USB Capture AIO - one-channel HD capture box

USB Capture AIO

Code: 32110 EAN/UPC: 6936572400037


Brand: MAGEWELL


€ 529,00 + VAT
Recommended End User Price
  • € 529,00 + VAT
  • Recommended End User Price
  •


Description:

One-channel HD capture box

  • DATA SHEET
  • COMPATIBLE ACCESSORIES
  • DOCUMENTS


Overview

  • Tipology:
  • Finished product
  • Product category:
  • Acquisition card
  • Family:
  • SDI/HDMI > USB
  • Product line:
  • Converter

Weight & dimensions

  • Width
  • 40,2 mm
  • Depth
  • 12,3 mm
  • Height
  • 92,2 mm

Performance

  • Product colour
  • Silver, White
  • Internal
  • Yes
  • Host interface
  • PCIe
  • Video capture resolution (max)
  • 4096 x 2160 pixels
  • LED indicators
  • Yes
  • Plug and Play
  • Yes

Ports & interfaces

  • HDMI version
  • 1.3
  • USB ports quantity
  • 1
  • USB version
  • 3.2 Gen 1 (3.1 Gen 1)
  • USB port
  • No

Power

  • Output current
  • 1,84 A
  • Power supply type
  • DC
  • Input voltage
  • 12 V

Operational conditions

  • Operating temperature (T-T)
  • 0 - 50 °C
  • Storage temperature (T-T)
  • -20 - 70 °C
  • Operating relative humidity (H-H)
  • 5 - 90%

Video

  • Supported video modes
  • 1080p
  • Maximum frame rate
  • 144 fps

Packaging content

  • Quantity
  • 1

Software

  • Windows operating systems supported
  • Yes
  • Mac operating systems supported
  • Yes
  • Linux operating systems supported
  • Yes
