SVC100

Code: 61V2B10000AC




€ 3.999,00 + VAT
Recommended End User Price
  • € 3.999,00 + VAT
  • Recommended End User Price
  •


Description:

Full HD Endpoint Video Conferencing System
As the next generation of AVer’s video conferencing system, the SVC100 was endowed with a futuristic design. The most standout feature is the stand with a curved design which supports a powerful 18X total zoom lens. Moreover, H.323, SIP, and Skype for Business support provide endless communication possibilities. The dual-camera/dual-presentation elevates AVer’s video conferencing system to the next level; providing users with unparalleled video conferencing experience.

Brand New Future ID Design
The SVC100 was endowed with a futuristic design the stylish “orbit” theme can be seen on the camera, codec, microphone, and even the user interface. The SVC100 conveys our product concept perfectly it is the best choice for next-gen work space.

H.323, SIP, and Skype for Business Support
The SVC100 can receive and share content as well as live videos. The integrated Skype for Business provides endless collaborative communication possibilities. In addition, H.323 and SIP protocols are also integrated to empower the SVC100’s multi-communication capabilities.

Supports Dual-Camera/Dual-Presentation
More options are available on the SVC100. Now, you can choose to show the 1st camera, the 2nd camera, or both. The SVC100 can also accept input from multiple sources. With two input sources available on the codec, users can choose to use HDMI, DVI/VGA, or both at the same time. The SVC100 is capable of providing an unparalleled video conferencing experience!

RTMP for Live Video Streaming
Live streaming functionality is ready in SVC100. You could live stream video conferencing, presentation, speech, lecture, etc. with an easy setup. Furthermore, SVC100 thinks one step ahead the vital recording function is also just a click away.

Built-in 32G Recording Storage Capacity
No more fumbling around for a USB drive when you need to record a meeting the SVC100 is equipped with 32 GB of internal storage. In addition, iSCSI functionality is also available for cloud upload. You will never have to miss another event!

Supports License Upgrade up to 16 Sites
Users can take advantage of our license upgrade program to expand up to 16 sites. The system can be expanded easily to meet your company’s growing communication needs.

  • DATA SHEET
  • COMPATIBLE ACCESSORIES
  • DOCUMENTS


Overview

  • Tipology:
  • Kit
  • Product category:
  • Collaboration
  • Family:
  • PTZ Indoor
  • Product line:
  • Full Hd 1080P
  • Cat-Aver1
  • ZOOM OTTICO 18X
  • Cat-Aver2
  • MULTIPUNTO

Weight & dimensions

  • Package width
  • 422 mm
  • Package depth
  • 336 mm
  • Package height
  • 374 mm
  • Package weight
  • 8,88 kg
  • Microphone dimensions (WxHxD)
  • 144.8 x 128.45 x 27.8 mm
  • Interface module dimensions (W x D x H)
  • 320 x 267 x 37.3 mm
  • Camera dimensions (WxDxH)
  • 205 x 205 x 195 mm

Performance

  • Product colour
  • Silver
  • Tilt angle range
  • -25 - 25°
  • PTZ control
  • Yes
  • Pan range
  • -110 - 110°

Ports & interfaces

  • USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
  • 1
  • HDMI ports quantity
  • 2
  • DC-in jack
  • Yes
  • Ethernet LAN (RJ-45) ports
  • 1
  • USB 2.0 ports quantity
  • 2
  • Line-in
  • Yes
  • DVI-D ports quantity
  • 1
  • USB connector type
  • USB Type-A
  • Line-out
  • Yes

Power

  • AC input voltage
  • 100 - 240 V
  • DC input voltage
  • 12 V
  • AC input frequency
  • 50 - 60 Hz
  • Current
  • 6,25 A

Operational conditions

  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage temperature (T-T)
  • -20 - 60 °C
  • Operating relative humidity (H-H)
  • 20 - 80%
  • Storage relative humidity (H-H)
  • 20 - 80%

Network

  • Ethernet LAN
  • Yes
  • Ethernet LAN data rates
  • 10,100,1000 Mbit/s
  • Security algorithms
  • 128-bit AES
  • Web-based management
  • Yes

Video

  • Supported video modes
  • 1080p
  • HD type
  • Full HD
  • Video formats supported
  • H.239, H.261, H.263, H.263+, H.264
  • Image formats supported
  • BMP, GIF, JPG, PNG

Packaging content

  • Remote control included
  • Yes
  • User guide
  • Yes
  • Camera included
  • Yes

Audio

  • Echo cancellation
  • Yes
  • Noise reduction
  • Yes
  • Voice codecs
  • G.711, G.722, G.722.1, G.722.1C, G.728
  • Automatic gain control
  • Yes

Memory

  • Total storage capacity
  • 32 GB

Camera

  • Horizontal field of view
  • 72°
  • Megapixel (approx.)
  • 2 MP
  • Sensor type
  • CMOS

Microphone

  • Microphone colour
  • Grey
  • Number of microphones
  • 1
