Description:
- Supports up to 4096x2160 60fps (4:2:0) or 30fps (4:4:4), down-converting them to HD NDI
- Connects existing source equipment into NDI-enabled, IP-based media networks
- Plug-and-play ease of use with automatic input format detection and DHCP network configuration
- DATA SHEET
- DOCUMENTS
Overview
- Tipology:
- Finished product
- Product category:
- Signal Distribution
- Family:
- HDMI > NDI
- Product line:
- Converter
Features
- Product colour
- Black
- LED indicators
- Yes
- Converter type
- Active video converter
- Internal
- No
Weight & dimensions
- Width
- 66,7 mm
- Depth
- 117,5 mm
- Height
- 23,4 mm
Ports & interfaces
- Host interface
- HDMI
- Output interface
- HDMI
Power
- Operating voltage
- 5 V
- Operating current
- 2 A
- Power consumption (typical)
- 8 W
- USB powered
- Yes
Operational conditions
- Operating temperature (T-T)
- 0 - 45 °C
- Storage temperature (T-T)
- -20 - 70 °C
- Operating relative humidity (H-H)
- 5 - 90%
Video
- Supported video modes
- 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
- Maximum video resolution
- 4096 x 2160 pixels
- Resolution at capture speed
- 4096x2160@30fps
- Video resolutions
- 720 x 480,720 x 576,1280 x 720,1920 x 1080,2048 x 1080
- Supported chroma subsampling
- 4:2:2, 4:4:4, 4:2:0
- Colour depth
- 8 bit
- Colour space supported
- RGB, YUV
- Serial Digital Interface (SDI) standard
- ITU‑R BT.601
