Description:
- Connects baseband presentation or distribution equipment into IP-based media networks
- Supports NDI technology including full-bandwidth NDI and high-efficiency NDI|HX mode
- Supports streaming protocols including SRT, RTSP, RTMP, UDP, RTP, HLS and HTTP
- DATA SHEET
- DOCUMENTS
Overview
- Tipology:
- Finished product
- Product category:
- Signal Distribution
- Family:
- NDI/SDI
- Product line:
- Converter
Features
- Product colour
- Black
- LED indicators
- Yes
- Converter type
- Active video converter
- Internal
- No
Weight & dimensions
- Width
- 60,2 mm
- Depth
- 100,9 mm
- Height
- 23,3 mm
Ports & interfaces
- Host interface
- USB 3.2 Gen 1 (3.1 Gen 1)
- Output interface
- SDI
- BNC video output
- Yes
- BNC output ports
- 1
Power
- Operating voltage
- 5 V
- Operating current
- 1,05 A
- Power consumption (typical)
- 5,5 W
- USB powered
- Yes
Operational conditions
- Operating temperature (T-T)
- 0 - 45 °C
- Storage temperature (T-T)
- -20 - 70 °C
- Operating relative humidity (H-H)
- 5 - 90%
Video
- Supported video modes
- 480i, 576i, 720p, 1080i, 1080p
- Maximum video resolution
- 1920 x 1080 pixels
- Resolution at capture speed
- 1920x1080@60fps
- Video resolutions
- 720 x 480,720 x 576,1280 x 720,1920 x 1080
- Colour space supported
- YUV
Audio
- Audio output channels
- 8.0 canali
- Audio sampling rate
- 48 kHz
