AU-A50

Code: AU-A50


Brand: CYP




Description:

The AU-A50 is a compact 2 channel digital zone amplifier that is perfect for providing high quality audio distribution into remote AV zones within any multi-room installation. This advanced solution can integrate digital and analogue audio signals from multiple sources, including an audio output from a TV, enabling sound re-enforcement within any zone.

  • DATA SHEET
  • DOCUMENTS


Overview

  • Tipology:
  • Finished product
  • Product category:
  • Signal Distribution
  • Family:
  • Amplificatore da installazione
  • Product line:
  • A zone
  • Cat-Cyp
  • MULTI ZONE

Packaging data

  • Package weight
  • 1,68 kg

Technical details

  • Product colour
  • Black
  • Material
  • Aluminium
  • Purpose
  • Home
  • Connectivity technology
  • Wired
  • Cooling type
  • Passive
  • Remote control type
  • RS-232, IR
  • Channels quantity
  • 2 canali

Weight & dimensions

  • Weight
  • 1,38 kg
  • Width
  • 215 mm
  • Depth
  • 150 mm
  • Height
  • 50 mm

Display

  • Built-in display
  • Yes

Ports & interfaces

  • DC-in jack
  • Yes
  • Audio (L/R) in
  • 1
  • USB 2.0 ports quantity
  • 1
  • Digital audio coaxial in
  • 1
  • Digital audio optical in
  • 1

Power

  • Power consumption (typical)
  • 52 W
  • DC input voltage
  • 24 V
  • Maximum current
  • 3,75 A

Operational conditions

  • Operating temperature (T-T)
  • 0 - 40 °C
  • Storage temperature (T-T)
  • -20 - 60 °C
  • Operating relative humidity (H-H)
  • 20 - 90%

Audio

  • Signal-to-Noise Ratio (SNR)
  • 70 dB
  • Peak power per channel
  • 30 W
  • Amplifier class
  • D
  • RMS power output per channel (4 Ohm)
  • 45 W
  • RMS power output per channel (8 Ohm)
  • 25 W

Indication

  • LED indicators
  • Yes
